395-144 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 144POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Flange Feature | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Features | Color | Number of Rows [custom] | Contact Finish | Pitch | Pitch | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Positions | Gender | Number of Positions/Bay/Row [custom] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | -40 C | 105 ░C | Non Specified - Dual Edge | Card Extender Card Guides | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount M3 Threaded Insert Top Opening | Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Black | 2 | Gold | 0.1 " | 2.54 mm | Wire Wrap | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Card Guides | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Board Edge Straddle Mount | -40 C | 105 ░C | Non Specified - Dual Edge | Card Extender Card Guides | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | M3 Threaded Insert Top Mount Opening | Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Black | 2 | Gold | 0.1 " | 2.54 mm | Wire Wrap | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount Side Opening Unthreaded | Board Edge Straddle Mount | -40 C | 105 ░C | Non Specified - Dual Edge | Card Extender | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | 0.128 " | 3.25 mm |
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Card Guides | Black | 2 | Gold | 0.1 " | 2.54 mm | Wire Wrap | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | M3 Threaded Insert Top Mount Opening | Right Angle Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Through Hole | -40 C | 105 ░C | Non Specified - Dual Edge | Black | 2 | Gold | 0.1 " | 2.54 mm | Solder | 0.25 Ám | 10 Áin | Copper Alloy | 144 | Female | 72 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Cantilever |
