MRF5 Series

Catalog

RF MOSFET LDMOS 28V NI780

Part	Package / Case	Voltage - Test	Power - Output	Gain	Frequency	Current - Test	Supplier Device Package	Voltage - Rated	Frequency [Min]	Frequency [Max]	Mounting Type
Freescale Semiconductor - NXP MRF5S4140HR5	SOT-957A	28 V	28 W	21 dB	465 MHz	1.25 A	NI-780H-2L	65 V
Freescale Semiconductor - NXP MRF5S9150HR5	SOT-957A	28 V	33 W	19.7 dB	880 MHz	1.5 A	NI-780H-2L	68 V
Freescale Semiconductor - NXP MRF5S9100NR1	TO-270AB	26 V	20 W	19.5 dB	880 MHz	950 mA		68 V
Freescale Semiconductor - NXP MRF5S9101MBR1	TO-272BB	26 V	100 W	17.5 dBi	960 MHz	700 mA	TO-272 WB-4	68 V
Freescale Semiconductor - NXP MRF5S21090HR5	SOT-957A	28 V	19 W	14.5 dBi	2.11 GHz	850 mA	NI-780H-2L	65 V
Freescale Semiconductor - NXP MRF5S21130HSR5	NI-880S	28 V	28 W	13.5 dB		1.2 A	NI-880S	65 V	2.11 GHz	2.17 GHz
Freescale Semiconductor - NXP MRF5S9080NR1	TO-270AB	26 V	80 W	18.5 dBi	960 MHz	600 mA		65 V			Surface Mount
Freescale Semiconductor - NXP MRF5S4140HR3	SOT-957A	28 V	28 W	21 dB	465 MHz	1.25 A	NI-780H-2L	65 V
Freescale Semiconductor - NXP MRF5S19150HSR5	NI-880S	28 V	32 W	14 dBi		1.4 A	NI-880S	65 V	1.93 GHz	1.99 GHz
Freescale Semiconductor - NXP MRF5S19060NBR1	TO-272BB	28 V	12 W	14 dBi	1.99 GHz	750 mA	TO-272 WB-4	65 V			Chassis Mount
