74LVC3G34 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
NOW NEXPERIA 74LVC3G34 - TRIPLE
| Part | Mounting Type | Logic Type | Package Width | Package Name | Package Length | Number of Elements | Package / Case | Current - Output High | Current - Output Low | Output Type | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Number of Bits per Element | Operating Temperature (Max) | Operating Temperature (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Surface Mount | Buffer Non-Inverting | 1 mm | 8-XSON | 1.35 mm | 3 | 8-XFDFN | 32 mA | 32 mA | Push-Pull | 1.65 V | 5.5 V | 1 bits | 125 °C | -40 °C |
 NXP USA Inc. | Surface Mount | Buffer Non-Inverting | 1 mm | 8-XSON | 1.2 mm | 3 | 8-XFDFN | 32 mA | 32 mA | Push-Pull | 1.65 V | 5.5 V | 1 bits | 125 °C | -40 °C |
 NXP USA Inc. | Surface Mount | Buffer Non-Inverting | 1.6 mm | 8-XQFN | 1.6 mm | 3 | 8-XFQFN Exposed Pad | 32 mA | 32 mA | Push-Pull | 1.65 V | 5.5 V | 1 bits | 125 °C | -40 °C |
 NXP USA Inc. | Surface Mount | Buffer Non-Inverting | 1 mm | 8-XSON | 1.95 mm | 3 | 8-XFDFN | 32 mA | 32 mA | Push-Pull | 1.65 V | 5.5 V | 1 bits | 125 °C | -40 °C |
