MMA72 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
ACCEL 1.5-6G ANALOG 16QFN
| Part | Type | Bandwidth | Mounting Type | Package / Case | Package Length | Package Name | Package Width | Operating Temperature (Min) | Operating Temperature (Max) | Features | Acceleration Range | Acceleration Typical | Acceleration Range (Minimum) | Acceleration Peak | Acceleration Range (Maximum) | Axis | Output Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Sensitivity Maximum (mV/g) | Sensitivity Minimum (mV/g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Analog | 150 Hz 350 Hz | Surface Mount | 16-LQFN Exposed Pad | 6 mm | 16-QFN | 6 mm | -40 °C | 105 °C | Selectable Scale Sleep Mode | ±1.5g 2g 4g 6g | 2 g | -1.5 g | 4 g | 1.5 g | X Y Z | Analog Voltage | 3.6 V | 2.2 V | 800 mV/g | 200 mV/g |
NXP USA Inc. | Analog | 150 Hz 350 Hz | Surface Mount | 16-LQFN Exposed Pad | 6 mm | 16-QFN | 6 mm | -40 °C | 105 °C | Selectable Scale Sleep Mode | ±1.5g 2g 4g 6g | 2 g | -1.5 g | 4 g | 1.5 g | X Y Z | Analog Voltage | 3.6 V | 2.2 V | 800 mV/g | 200 mV/g |
