74LVC1G11 Series

Catalog

IC GATE AND 1CH 3-INP 6TSSOP

Part	Package / Case	Qualification	Max Propagation Delay @ V, Max CL [Max]	Number of Circuits	Number of Inputs	Logic Type	Grade	Voltage - Supply [Max]	Voltage - Supply [Min]	Input Logic Level - Low [Max]	Input Logic Level - Low [Min]	Current - Output High, Low [y]	Current - Output High, Low [x]	Operating Temperature [Max]	Operating Temperature [Min]	Input Logic Level - High [Min]	Input Logic Level - High [Max]	Supplier Device Package	Mounting Type	Current - Quiescent (Max) [Max]
Freescale Semiconductor - NXP 74LVC1G11GW-Q100H	6-TSSOP SC-88 SOT-363	AEC-Q100	3.5 ns	1	3	AND Gate	Automotive	5.5 V	1.65 V	0.8 V	0.7 V	32 mA	32 mA	125 °C	-40 °C	1.7 V	2 V	6-TSSOP	Surface Mount	4 µA
Freescale Semiconductor - NXP 74LVC1G11GXZ
Freescale Semiconductor - NXP 74LVC1G11GV,125	SC-74 SOT-457		3.5 ns	1	3	AND Gate		5.5 V	1.65 V	0.8 V	0.7 V	32 mA	32 mA	125 °C	-40 °C	1.7 V	2 V	6-TSOP	Surface Mount	4 µA
Freescale Semiconductor - NXP 74LVC1G11GV-Q100H	SC-74 SOT-457	AEC-Q100	3.5 ns	1	3	AND Gate	Automotive	5.5 V	1.65 V	0.8 V	0.7 V	32 mA	32 mA	125 °C	-40 °C	1.7 V	2 V	6-TSOP	Surface Mount	4 µA
