292253 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CT HDR ASSY H 6P BLACK

Part	Contact Length - Post	Contact Length - Post [x]	Fastening Type	Termination	Style	Connector Type	Current Rating (Amps)	Shrouding	Contact Finish - Post	Number of Positions	Applications	Number of Positions Loaded	Number of Rows	Voltage Rating	Pitch - Mating [x]	Pitch - Mating [x]	Insulation Material	Contact Shape	Contact Length - Mating	Contact Length - Mating	Contact Material	Mounting Type	Material Flammability Rating	Insulation Color	Insulation Height [custom]	Insulation Height [custom]	Contact Type
TE Connectivity Raychem Cable Protection 6-292253-6	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin	6	General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Black	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 1-292253-5	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin	15	General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Natural	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 292253-5	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin		General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Natural	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 4-292253-2	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin	2	General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Yellow	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 6-292253-5	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin		General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Black	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 292253-9	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin	9	General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Natural	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 292253-3	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin		General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Natural	0.157 in	4 mm	Male Pin
TE Connectivity Raychem Cable Protection 292253-2	3.2 mm	0.126 in	Detent Lock	Kinked Pin Solder	Board to Cable/Wire	Header	Varies by Wire Gauge	Shrouded - 3 Wall	Tin	2	General Purpose	All	1	125 VAC	0.079 in	2 mm	Polyamide (PA66) Nylon 6/6	Circular	0.177 in	4.5 mm	Brass	Through Hole Right Angle	UL94 V-0	Natural	0.157 in	4 mm	Male Pin
