zelio-relay Series
Manufacturer: SCHNEIDER ELECTRIC
Beta
⌘K
RELAY: ELECTROMAGNETIC; 4PDT; 24VAC; ICONTACTS MAX: 15A
| Part | Coil Resistance | Contact Rating (Current) | Load - Max Switching | Must Release Voltage | Release Time | Approval Agency | Contact Material | Relay Type | Must Operate Voltage | Features | Termination Style | Operate Time | Coil Current | Coil Type | Switching Voltage [Max] | Contact Form | Operating Temperature [Max] | Operating Temperature [Min] | Coil Voltage | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHNEIDER ELECTRIC | 80 Ohms | 15 A | 420 W 3750 VA | 3.6 VAC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 19.2 VAC | Lighted Indicator Test Button | Plug In | 20 ms | 300 mA | Non Latching | 28 VDC 250 VAC | 4PDT (4 Form C) | 55 °C | -40 C | 24 VAC | Socketable |
 SCHNEIDER ELECTRIC | 15 A | 420 W 3750 VA | 1.2 VDC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 9.6 VDC | Lighted Indicator Test Button | Plug In | 20 ms | 104.3 mA | Non Latching | 28 VDC 250 VAC | SPDT (1 Form C) | 55 °C | -40 C | 12 VDC | Socketable | |
 SCHNEIDER ELECTRIC | 9.6 kOhms | 15 A | 420 W 3750 VA | 34.5 VAC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 184 VAC | Lighted Indicator Test Button | Plug In | 20 ms | 24 mA | Non Latching | 28 VDC 250 VAC | 3PDT (3 Form C) | 55 °C | -40 C | 230 VAC | Socketable |
 SCHNEIDER ELECTRIC | 6 A | 1662 VA | 3 VDC | 20 ms | CSA GOST UL | Silver Tin Oxide (AgSnO) | General Purpose | Lighted Indicator | Spring Terminal | 12 ms | 2.9 mA | Non Latching | 277 VAC | SPDT (1 Form C) | 70 °C | -40 C | 60 VDC | Socketable | ||
 SCHNEIDER ELECTRIC | 15 A | 420 W 3750 VA | 34.5 VAC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 184 VAC | Lighted Indicator Test Button | Plug In | 20 ms | 31.3 mA | Non Latching | 28 VDC 250 VAC | 4PDT (4 Form C) | 55 °C | -40 C | 230 VAC | Socketable | |
 SCHNEIDER ELECTRIC | 160 Ohms | 15 A | 420 W 3750 VA | 1.2 VDC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 9.6 VDC | Lighted Indicator Test Button | Plug In | 20 ms | 0.075 A | Non Latching | 28 VDC 250 VAC | DPDT (2 Form C) | 55 °C | -40 C | 12 VDC | Socketable |
 SCHNEIDER ELECTRIC | 15 A | 420 W 3750 VA | 11 VDC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 88 VDC | Test Button | Plug In | 20 ms | 17.3 mA | Non Latching | 28 VDC 250 VAC | 4PDT (4 Form C) | 55 °C | -40 C | 110 VDC | Socketable | |
 SCHNEIDER ELECTRIC | 10 A | 280 W 2500 VA | 11 VDC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 88 VDC | Lighted Indicator Test Button | Plug In | 20 ms | 15.1 mA | Non Latching | 28 VDC 250 VAC | DPDT (2 Form C) | 55 °C | -40 C | 110 VDC | Socketable | |
 SCHNEIDER ELECTRIC | 848 Ohms | 6 A | 1662 VA | 0.6 VDC | 12 ms | CSA GOST UL | Silver Tin Oxide (AgSnO) | General Purpose | Lighted Indicator | Screw Terminal | 5 ms | 14.2 mA | Non Latching | 277 VAC | SPDT (1 Form C) | 55 °C | -40 C | 12 VDC | DIN Rail | |
 SCHNEIDER ELECTRIC | 7.3 kOhms | 10 A | 280 W 2500 VA | 12.5 VDC | 20 ms | CSA EAC UL | Silver Nickel (AgNi) | General Purpose | 100 VDC | Test Button | Plug In | 20 ms | 17.1 mA | Non Latching | 28 VDC 250 VAC | 3PDT (3 Form C) | 55 °C | -40 C | 125 VDC | Socketable |
