PWC-5 Series
Manufacturer: Astrodyne TDI
Beta
⌘K
AC/DC CONVERTER 5V 5W
| Part | Line Regulation | Load Regulation | Approval Agency | Voltage - Output 1 | Type | Features | Operating Temperature [Min] | Operating Temperature [Max] | Power (Watts) | Voltage - Input [Max] | Voltage - Input [Min] | Efficiency | Package / Case | Number of Outputs | Applications | Mounting Type | Current - Output (Max) [Max] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Standard Number | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Astrodyne TDI | 0.5 % | ±1% | CE cURus UL | 5 V | Enclosed | Universal Input | -25 °C | 65 °C | 5 W | 264 VAC | 90 VAC | 72 % | 4-DIP Module | 1 | ITE (Commercial) | Through Hole | 1 A | 50.8 mm | 0.6 " | 2 in | 15.2 mm | 25.4 mm | 1 " | |||
 Astrodyne TDI | 1 % | ±1% | cURus UL | 5 V | Open Frame | Universal Input | -25 °C | 65 °C | 5 W | 264 VAC | 90 VAC | 72 % | 6-SIP Module | 1 | ITE (Commercial) Medical | Through Hole | 1 A | 49 mm | 1.12 " | 1.93 in | 28.5 mm | 13 mm | 0.51 in | 60601-1 60950-1 | ||
 Astrodyne TDI | 1 % | ±1% | cURus UL | 5 V | Enclosed | Universal Input | -25 °C | 65 °C | 5 W | 264 VAC | 90 VAC | 72 % | 6-SIP Module | 1 | ITE (Commercial) Medical | Through Hole | 1 A | 52.1 mm | 1.24 " | 2.05 in | 0.63 " | 60601-1 60950-1 | 31.5 mm | 16 mm |
