29125 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE DPDT 6A 24V
| Part | Coil Resistance | Termination Style | Release Time | Contact Form | Operating Temperature [Max] | Operating Temperature [Min] | Coil Voltage | Coil Type | Coil Current | Mounting Type | Operate Time | Relay Type | Contact Rating (Current) | Contact Material | Switching Voltage | Features | Coil Voltage | Coil Voltage | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 2.182 kOhms | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | 24 VAC | Non Latching | 17.5 mA | DIN Rail | 8 ms | General Purpose | 6 A | Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator Socket Included | |||
 Phoenix Contact | 1.37 kOhms | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | 24 VAC | Non Latching | 17.5 mA | DIN Rail | 8 ms | General Purpose | 6 A | Gold (Au) Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator | |||
 Phoenix Contact | 1.33 kOhms | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | 24 VDC | Non Latching | 18 mA | DIN Rail | 8 ms | General Purpose | 6 A | Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator Socket Included | |||
 Phoenix Contact | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | Non Latching | 4.5 mA | DIN Rail | 7 ms | General Purpose | 6 A | Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator Socket Included | 120VAC/DC | ||||
Phoenix Contact | 364 Ohms | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | 12 VDC | Non Latching | 33 mA | DIN Rail | 8 ms | General Purpose | 6 A | Gold (Au) Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator Socket Included | |||
 Phoenix Contact | 2.4 kOhms | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | 48 VDC | Non Latching | 0.02 A | DIN Rail | 8 ms | General Purpose | 6 A | Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator Socket Included | |||
 Phoenix Contact | 1.33 kOhms | Spring Terminal | 10 ms | DPDT (2 Form C) | 60 °C | -40 C | 24 VDC | Non Latching | 18 mA | DIN Rail | 8 ms | General Purpose | 6 A | Gold (Au) Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator Socket Included | |||
Phoenix Contact | 51.11 kOhms | Spring Terminal | 10 ms | DPDT (2 Form C) | 55 °C | -40 C | Non Latching | 4.5 mA | DIN Rail | 7 ms | General Purpose | 6 A | Silver Nickel (AgNi) | 250 VAC 250 VDC | Lighted Indicator | 230 VDC | 230 VAC |
