627-M25 Series
Manufacturer: EDAC Inc.
Beta
⌘K
D SUB CONNECTOR, STANDARD, PLUG, 627M SERIES, 25 CONTACTS, DB, SOLDER CUP
| Part | Dielectric Material | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Finish Thickness | Material Flammability Rating | Current Rating (Amps) | Mounting Type | Connector Type | Shell Material, Finish | Features | Connector Style | Flange Feature | Number of Rows [custom] | Number of Positions | Contact Type | Contact Finish | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Termination | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | White | Flash | UL94 V-0 | 5 A | Free Hanging (In-Line) | Plug Male Pins | Nickel Plated Steel | Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | White | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Nickel Plated Steel | Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | 0.38 µm | 15 µin | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | Blue | UL94 V-0 | 5 A | Free Hanging (In-Line) | Plug Male Pins | Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | 0.38 µm | 15 µin | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | Blue | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | 0.38 µm | 15 µin | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | White | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Nickel Plated Steel | Board Lock Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | 0.38 µm | 15 µin | |
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | White | UL94 V-0 | 5 A | Free Hanging (In-Line) | Plug Male Pins | Nickel Plated Steel | Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | 0.38 µm | 15 µin | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | Green | Flash | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Nickel Plated Steel | Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | Green | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Board Lock Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | 0.38 µm | 15 µin | ||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | White | Flash | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Board Lock Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | |||
 EDAC Inc. | Polyamide (PA6T) Nylon 6T | Copper Alloy | -55 C | 125 °C | White | UL94 V-0 | 5 A | Through Hole | Plug Male Pins | Nickel Plated Steel | Board Lock Grounding Indents Shielded | D-Sub | Board Side (4-40) | 2 | 25 | Signal | Gold | B DB | 3 | Solder | 0.38 µm | 15 µin |
