2316952 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
3.96 EP HDR ASSY 9P, NO PIN 2,4,
| Part | Termination | Contact Type | Number of Positions | Mounting Type | Contact Material | Contact Length - Mating | Contact Length - Mating | Current Rating (Amps) | Insulation Height | Insulation Height | Material Flammability Rating | Style | Contact Shape | Insulation Color | Operating Temperature [Min] | Operating Temperature [Max] | Shrouding | Overall Contact Length | Overall Contact Length | Number of Rows | Insulation Material | Contact Length - Post | Contact Length - Post | Pitch - Mating | Pitch - Mating | Applications | Fastening Type | Contact Finish - Post | Connector Type | Voltage Rating | Number of Positions Loaded | Number of Positions Loaded [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Solder | Male Pin | 9 | Through Hole | Brass | 7.7 mm | 0.303 in | 8 A | 0.362 in | 9.2 mm | UL94 V-0 | Board to Board Cable | Square | Natural | -30 ░C | 105 ░C | Shrouded - 1 Wall | 14.4 mm | 0.567 " | 1 | Polybutylene Terephthalate (PBT) | 0.146 in | 3.7 mm | 0.156 in | 3.96 mm | General Purpose | Locking Ramp | Tin | Header | 250 VDC | ||
TE Connectivity Raychem Cable Protection | Solder | Male Pin | 6 | Through Hole | Brass | 7.7 mm | 0.303 in | 8 A | 0.362 in | 9.2 mm | UL94 V-0 | Board to Board Cable | Square | Natural | -30 ░C | 105 ░C | Shrouded - 1 Wall | 14.4 mm | 0.567 " | 1 | Polybutylene Terephthalate (PBT) | 0.146 in | 3.7 mm | 0.156 in | 3.96 mm | General Purpose | Locking Ramp | Tin | Header | 250 VDC | 4 | |
 TE Connectivity Raychem Cable Protection | Solder | Male Pin | 8 | Through Hole | Brass | 7.7 mm | 0.303 in | 8 A | 0.362 in | 9.2 mm | UL94 V-0 | Board to Board Cable | Square | Natural | -30 ░C | 105 ░C | Shrouded - 1 Wall | 14.4 mm | 0.567 " | 1 | Polybutylene Terephthalate (PBT) | 0.146 in | 3.7 mm | 0.156 in | 3.96 mm | General Purpose | Locking Ramp | Tin | Header | 250 VDC | ||
TE Connectivity Raychem Cable Protection | Solder | Male Pin | 8 | Through Hole | Brass | 7.7 mm | 0.303 in | 8 A | 0.362 in | 9.2 mm | UL94 V-0 | Board to Board Cable | Square | Natural | -30 ░C | 105 ░C | Shrouded - 1 Wall | 14.4 mm | 0.567 " | 1 | Polybutylene Terephthalate (PBT) | 0.146 in | 3.7 mm | 0.156 in | 3.96 mm | General Purpose | Locking Ramp | Tin | Header | 250 VDC | 5 | |
TE Connectivity Raychem Cable Protection | Solder | Male Pin | 10 | Through Hole | Brass | 7.7 mm | 0.303 in | 8 A | 0.362 in | 9.2 mm | UL94 V-0 | Board to Board Cable | Square | Natural | -30 ░C | 105 ░C | Shrouded - 1 Wall | 14.4 mm | 0.567 " | 1 | Polybutylene Terephthalate (PBT) | 0.146 in | 3.7 mm | 0.156 in | 3.96 mm | General Purpose | Locking Ramp | Tin | Header | 250 VDC |
