Coupled Inductors IND DBL PWR 1.5UH
Coupled Inductors IND DBL PWR 1.5UH
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Current Rating - Parallel | Inductance - Connected In Series | Inductance - Connected In Parallel | Height [z] | Height [z] | DC Resistance (DCR) - Series [Max] | Number of Coils | Current Saturation - Parallel | Shielding | Current Saturation - Series | Current Rating - Series | Tolerance | Package / Case | DC Resistance (DCR) - Parallel [Max] | DC Resistance (DCR) - Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | 125 °C | -40 C | Surface Mount | 12.5 mm | 0.492 " | 12.5 mm | 0.492 " | 3.2 A | 190 µH | 47 µH | 0.236 in | 6 mm | 270 mOhm | 2 | 3.2 A | Shielded | 1.6 A | 1.7 A | 20 % | Nonstandard | 69 mOhm | |
 Pulse Electronics | 125 °C | -40 C | Surface Mount | 12.5 mm | 0.492 " | 12.5 mm | 0.492 " | 3.7 A | 135 µH | 34 µH | 0.236 in | 6 mm | 2 | 3.9 A | Shielded | 2 A | 1.9 A | 20 % | Nonstandard | 54 mOhm | 220 mOhm |
