638-M26 Series
Manufacturer: EDAC Inc.
Beta
⌘K
638M SERIES VERTICAL D-SUB RECEP
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Material | Color | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Mounting Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Flange Feature | Flange Feature | Material Flammability Rating | Number of Positions | Contact Type | Connector Type | Features | Number of Rows [custom] | Contact Finish | Contact Finish Thickness | Termination | Shell Material, Finish | Flange Feature [custom] | Flange Feature [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 30 Áin | 0.76 Ám | 5 A | Free Hanging (In-Line) | 2 | DA A | Housing/Shell | 4-40 | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Shielded | 3 | Gold | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 5 A | Through Hole | 2 | DA A | 4-40 | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Board Lock Shielded | 3 | Gold | Flash | Solder | Nickel Plated Steel | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 30 Áin | 0.76 Ám | 5 A | Through Hole | 2 | DA A | Board Side (4-40) | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Board Lock Shielded | 3 | Gold | Solder | Nickel Plated Steel | ||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 30 Áin | 0.76 Ám | 5 A | Free Hanging (In-Line) | 2 | DA A | Housing/Shell (Unthreaded) | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Shielded | 3 | Gold | Nickel Plated Steel | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 15 µin | 0.38 µm | 5 A | Free Hanging (In-Line) | 2 | DA A | Board Side (4-40) | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Board Lock Shielded | 3 | Gold | Nickel Plated Steel | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 5 A | Through Hole | 2 | DA A | Board Side (4-40) | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Board Lock Shielded | 3 | Gold | Flash | Solder | Nickel Plated Steel | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 15 µin | 0.38 µm | 5 A | Free Hanging (In-Line) | 2 | DA A | Board Side (4-40) | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Shielded | 3 | Gold | Nickel Plated Steel | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 30 Áin | 0.76 Ám | 5 A | Free Hanging (In-Line) | 2 | DA A | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Shielded | 3 | Gold | Nickel Plated Steel | 4-40 | 4-40 | ||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 30 Áin | 0.76 Ám | 5 A | Free Hanging (In-Line) | 2 | DA A | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Shielded | 3 | Gold | 4-40 | 4-40 | |||||
 EDAC Inc. | -55 C | 125 °C | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | D-Sub High Density | 15 µin | 0.38 µm | 5 A | Free Hanging (In-Line) | 2 | DA A | 4-40 | UL94 V-0 | 26 | Signal | Receptacle Female Sockets | Board Lock Shielded | 3 | Gold | Nickel Plated Steel |
