895-064 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 64POS 0.100
...
| Part | Number of Positions/Bay/Row | Number of Positions | Termination | Read Out | Mounting Type | Card Type | Material - Insulation | Termination Rows | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Color | Pitch | Pitch | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 64 | 64 | Solder | Single | Through Hole | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | |||
 EDAC Inc. | 32 | 64 | Solder | Dual | Through Hole | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | 2 | 2 | |||
 EDAC Inc. | 64 | 64 | Wire Wrap | Single | Through Hole | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | |||||
 EDAC Inc. | 32 | 64 | Solder | Dual | Board Edge Straddle Mount | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Copper Alloy | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | 2 | 2 | Card Extender | ||
 EDAC Inc. | 32 | 64 | Wire Wrap | Dual | Through Hole | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | 2 | 2 | |||
 EDAC Inc. | 32 | 64 | Solder | Dual | Through Hole | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Copper Alloy | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | 2 | 2 | |||
 EDAC Inc. | 32 | 64 | Wire Wrap | Dual | Through Hole | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Copper Alloy | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | 2 | 2 | |||
 EDAC Inc. | 64 | 64 | Solder | Single | Through Hole | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | M3 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | |||||
 EDAC Inc. | 64 | 64 | Solder | Single | Right Angle Through Hole | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female | |||
 EDAC Inc. | 64 | 64 | Wire Wrap | Single | Through Hole | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 1 | Copper Alloy | 3.96 mm | 0.156 " | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.1 " | 2.54 mm | 1 | 0.25 Ám | 10 Áin | Gold | 125 °C | -40 C | Female |
