RPM7020 Series
Manufacturer: Astrodyne TDI
Beta
⌘K
LINE FILTER 300VAC 5A CHASSIS
| Part | Voltage - Rated AC | Filter Type | Configuration | Current | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Frequency - Operating [Max] | Frequency - Operating [Min] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|
 Astrodyne TDI | 300 V | Single Phase | Two Stage | 5 A | -40 C | 100 °C | Threaded Post (M5) | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
 Astrodyne TDI | 300 V | Single Phase | Two Stage | 15 A | -40 C | 100 °C | Quick Connect | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 10 A | -40 C | 100 °C | Quick Connect | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 20 A | -40 C | 100 °C | Threaded Post (M5) | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 5 A | -40 C | 100 °C | Threaded Post (M5) | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 20 A | -40 C | 100 °C | Threaded Post (M5) | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 10 A | -40 C | 100 °C | Threaded Post (M5) | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 10 A | -40 C | 100 °C | Threaded Post (M5) | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 20 A | -40 C | 100 °C | Quick Connect | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
Astrodyne TDI | 300 V | Single Phase | Two Stage | 20 A | -40 C | 100 °C | Quick Connect | 60 Hz 400 Hz | 50 Hz | Chassis Mount |
