PKV332 Series

Catalog

DC DC CONVERTER +/-12V 3W

Part	Voltage - Output 1	Voltage - Input (Min) [Min]	Voltage - Input (Max) [Max]	Standard Number	Package / Case	Voltage - Output 2	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Isolation	Applications	Current - Output (Max)	Approval Agency	Power (Watts)	Type	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Mounting Type	Efficiency	Current - Output (Max)	Current - Output (Max)
Flex Power Modules PKV3321PI	12 V	9 V	36 V	62368-1	24-DIP Module 10 Leads	-12 V	0.42 "	0.8 "	10.7 mm	1.25 in	31.8 mm	20.3 mm	1.5 kV	ITE (Commercial)	125 mA	CB CSA IEC TUV UL	3 W	Isolated Module	95 °C	-40 °C	2	Through Hole
Flex Power Modules PKV3325PI	15 V	9 V	36 V	62368-1	24-DIP Module 10 Leads	-15 V	0.42 "	0.8 "	10.7 mm	1.25 in	31.8 mm	20.3 mm	1.5 kV	ITE (Commercial)		CB CSA IEC TUV UL	3 W	Isolated Module	95 °C	-40 °C	2	Through Hole	80 %	100 mA	100 mA
