M80-704 Series
Manufacturer: Harwin Inc.
Beta
⌘K
HEADER CONNECTOR,PCB MOUNT,PLUG,51 CONTACTS,SKT,0.079 PITCH,PC TAIL TERMINAL,LOCKING ROHS COMPLIANT: NO
| Part | Contact Material | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Material | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions Loaded | Connector Type | Style | Contact Finish - Post | Insulation Height | Insulation Height | Contact Type | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Termination | Mounting Type | Pitch - Mating | Pitch - Mating | Contact Length - Post | Contact Length - Post | Row Spacing - Mating | Row Spacing - Mating | Number of Rows [custom] | Material Flammability Rating | Number of Positions | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | Beryllium Copper | 157.5 Áin | 4 Ám | Glass Filled Nylon 4/6 Polyamide (PA46) | Circular | -55 C | 125 °C | All | Receptacle | Board to Board Cable | Tin-Lead | 6.28 mm | 0.247 " | Female Socket | Jackscrews Mating Flange Mounting Flange | 12 Áin | 0.3 Ám | Black | Solder | Through Hole | 0.079 " | 2 mm | 0.118 in | 3 mm | 2 mm | 0.079 in | 3 | UL94 V-0 | 51 | Gold |
 Harwin Inc. | Beryllium Copper | 12 µin | 0.3 µm | Glass Filled Nylon 4/6 Polyamide (PA46) | Circular | -55 C | 125 °C | All | Receptacle | Board to Board Cable | Gold | 6.28 mm | 0.247 " | Female Socket | Jackscrews Mating Flange Mounting Flange | 12 Áin | 0.3 Ám | Black | Solder | Through Hole | 0.079 " | 2 mm | 0.118 in | 3 mm | 2 mm | 0.079 in | 3 | UL94 V-0 | 45 | Gold |
Harwin Inc. | Beryllium Copper | 157.5 Áin | 4 Ám | Glass Filled Nylon 4/6 Polyamide (PA46) | Circular | -55 C | 125 °C | All | Receptacle | Board to Board Cable | Tin-Lead | 6.28 mm | 0.247 " | Female Socket | Jackscrews Mating Flange Mounting Flange | 12 Áin | 0.3 Ám | Black | Solder | Through Hole | 0.079 " | 2 mm | 0.118 in | 3 mm | 2 mm | 0.079 in | 3 | UL94 V-0 | 63 | Gold |
 Harwin Inc. | Beryllium Copper | 12 µin | 0.3 µm | Glass Filled Nylon 4/6 Polyamide (PA46) | Circular | -55 C | 125 °C | All | Receptacle | Board to Board Cable | Gold | 6.28 mm | 0.247 " | Female Socket | Jackscrews Mating Flange Mounting Flange | 12 Áin | 0.3 Ám | Black | Solder | Through Hole | 0.079 " | 2 mm | 0.118 in | 3 mm | 2 mm | 0.079 in | 3 | UL94 V-0 | 63 | Gold |
Harwin Inc. | Beryllium Copper | 12 µin | 0.3 µm | Glass Filled Nylon 4/6 Polyamide (PA46) | Circular | -55 C | 125 °C | All | Receptacle | Board to Board Cable | Gold | 6.28 mm | 0.247 " | Female Socket | Jackscrews Mating Flange Mounting Flange | 12 Áin | 0.3 Ám | Black | Solder | Through Hole | 0.079 " | 2 mm | 0.118 in | 3 mm | 2 mm | 0.079 in | 3 | UL94 V-0 | 36 | Gold |
