Tiny Pushbutton Switches
| Part | Actuator Type | Features | Voltage Rating - AC | Type | Color - Actuator/Cap | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - DC | Electrical Life | Switch Function | Circuit | Actuator Marking | Mounting Type | Current Rating (Amps) | Panel Cutout Dimensions [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 120 V | Standard | Black | Solder Lug | -30 ░C | 85 °C | 28 V | 60000 Cycles | Off-Mom | SPST-NO | No Marking | |||
 Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 20 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 20 V | 60000 Cycles | Off-Mom | SPST-NO | No Marking | Through Hole Right Angle | 0.4 VA | |
Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 20 V | Standard | Black | Solder Lug | -30 ░C | 85 °C | 20 V | 30000 Cycles | On-Mom | SPDT | No Marking | Panel Mount Rear | 0.4 VA | 4.95 mm |
Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 120 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 28 V | 30000 Cycles | On-Mom | SPDT | No Marking | Through Hole | ||
 Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 20 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 20 V | 60000 Cycles | Off-Mom | SPST-NO | No Marking | Right Angle Through Hole Vertical | 0.4 VA | |
Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 120 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 28 V | 60000 Cycles | Off-Mom | SPST-NO | No Marking | Panel Mount Rear | 0.25 in | |
 Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 20 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 20 V | 30000 Cycles | On-Mom | SPDT | No Marking | Right Angle Through Hole Vertical | 0.4 VA | |
 Littelfuse/Commercial Vehicle Products | Round Plunger | 120 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 28 V | 30000 Cycles | On-Mom | SPDT | No Marking | Through Hole | |||
Littelfuse/Commercial Vehicle Products | Round Plunger | 20 V | Standard | Black | Wire Wrap | -30 ░C | 85 °C | 20 V | 60000 Cycles | Off-Mom | SPST-NO | No Marking | Panel Mount Rear | 0.4 VA | 4.95 mm | |
Littelfuse/Commercial Vehicle Products | Round Plunger | Sealed | 20 V | Standard | Black | PC Pin | -30 ░C | 85 °C | 20 V | 60000 Cycles | Off-Mom | SPST-NO | No Marking | Through Hole | 0.4 VA |
Key Features
• Epoxy terminal seal-compatible with bottom wash cleaning
• Subminiature size - capable of switching 1 AMP
• Snap-in front panel mounting available
Description
AI
C&K’s TP series of tiny pushbutton switches are used most often in telecommunications, networking and instrumentation applications. The TP switches are well-known for their subminiature size and ability to switch at 1 AMP. Snap-in front panel mounting is available, as are vertical and right angle terminations – and their epoxy terminal seal is compatible with bottom wash cleaning.
