11_SMA-R50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_SMA-R50-3-238/133_NE
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Body Material | Center Contact Plating | Body Finish | Mating Cycles | Dielectric Material | Cable Group | Connector Type | Mounting Type | Frequency - Max [Max] | Contact Termination | Number of Ports | Impedance | Shield Termination | Housing Color | Fastening Type | Center Contact Material | Connector Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Brass | Gold | White Bronze | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RG-400 | Female Socket Plug | Free Hanging (In-Line) | 18 GHz | Solder | 1 | 50 Ohms | Crimp | Silver | Threaded | Beryllium Copper | RP-SMA |
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Brass | Gold | White Bronze | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RG-400 | Female Socket Plug | Free Hanging (In-Line) | 18 GHz | Solder | 1 | 50 Ohms | Crimp | Silver | Threaded | Beryllium Copper | RP-SMA |
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Brass | Gold | White Bronze | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RD-316 | Female Socket Plug | Free Hanging (In-Line) | 18 GHz | Solder | 1 | 50 Ohms | Crimp | Silver | Threaded | Beryllium Copper | RP-SMA |
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Brass | Gold | White Bronze | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | RG-58 | Female Socket Plug | Free Hanging (In-Line) | 18 GHz | Solder | 1 | 50 Ohms | Crimp | Silver | Threaded | Beryllium Copper | RP-SMA |
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Brass | Gold | White Bronze | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | LMR-240 | Female Socket Plug | Free Hanging (In-Line) | 18 GHz | Solder | 1 | 50 Ohms | Crimp | Silver | Threaded | Beryllium Copper | RP-SMA |
