627-47W Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB MIXED CONTACT CONNECTORS VERTICAL COMBO DSUB
| Part | Contact Material | Color | Voltage Rating | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Features | Current Rating (Amps) | Contact Type | Number of Rows [custom] | Flange Feature | Shell Size, Connector Layout | Shell Size, Connector Layout | Material Flammability Rating | Mounting Type | Connector Style | Termination | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Connector Type | Shell Material, Finish | Current Rating (Amps) | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Grounding Indents Shielded | 20A 5A | Signal and Power | 3 | Board Side (M3) | 47W1 D DD | 5 | UL94 V-0 | Panel Mount Through Hole | Combo D-Sub | Solder | 30 Áin | 0.76 Ám | 47 | Plug Male Pins | |||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Grounding Indents Shielded | Coax Signal | 3 | Board Side (M3) | 47W1 D DD | 5 | UL94 V-0 | Panel Mount Through Hole | Combo D-Sub | Solder | 30 Áin | 0.76 Ám | 47 | Plug Male Pins | ||||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Board Lock Grounding Indents Shielded | 20A 5A | Signal and Power | 3 | Board Side (4-40) | 47W1 D DD | 5 | UL94 V-0 | Through Hole | Combo D-Sub | Solder | 30 Áin | 0.76 Ám | 47 | Plug Male Pins | Nickel Plated Steel | ||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Grounding Indents Shielded | Coax Signal | 3 | Board Side (M3) | 47W1 D DD | 5 | UL94 V-0 | Free Hanging (In-Line) | Combo D-Sub | 30 Áin | 0.76 Ám | 47 | Plug Male Pins | |||||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Grounding Indents Shielded | Signal and Power | 3 | Housing/Shell (Unthreaded) | 47W1 D DD | 5 | UL94 V-0 | Free Hanging (In-Line) | Combo D-Sub | 30 Áin | 0.76 Ám | 47 | Plug Male Pins | 5 A 30 A | ||||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Board Lock Grounding Indents Shielded | Signal and Power | 3 | M3 | 47W1 D DD | 5 | UL94 V-0 | Panel Mount Through Hole | Combo D-Sub | Solder | 47 | Plug Male Pins | 5 A 40 A | Flash | ||||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Board Lock Grounding Indents Shielded | Coax Signal | 3 | Board Side (4-40) | 47W1 D DD | 5 | UL94 V-0 | Through Hole | Combo D-Sub | Solder | 47 | Plug Male Pins | Nickel Plated Steel | Flash | ||||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Board Lock Grounding Indents Shielded | Signal and Power | 3 | Board Side (4-40) | 47W1 D DD | 5 | UL94 V-0 | Through Hole | Combo D-Sub | Solder | 30 Áin | 0.76 Ám | 47 | Plug Male Pins | 5 A 30 A | |||
EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Grounding Indents Shielded | Signal and Power | 3 | Board Side (4-40) | 47W1 D DD | 5 | UL94 V-0 | Panel Mount Through Hole | Combo D-Sub | Solder | 47 | Plug Male Pins | 5 A 30 A | Flash | ||||
 EDAC Inc. | Copper Alloy | Black | 125 VDC | Polyester Thermoplastic | -55 C | 125 °C | Gold | Board Lock Grounding Indents Shielded | 10A 5A | Signal and Power | 3 | Board Side (M3) | 47W1 D DD | 5 | UL94 V-0 | Through Hole | Combo D-Sub | Solder | 30 Áin | 0.76 Ám | 47 | Plug Male Pins |
