YB15WS Series
Manufacturer: NKK Switches
Beta
⌘K
SPDT ON-(ON) PANEL SEAL SQUARE B
| Part | Electrical Life | Mechanical Life | Circuit | Type | Mounting Type | Features | Ingress Protection | Voltage Rating - AC | Actuator Marking | Operating Temperature [Min] | Operating Temperature [Max] | Panel Cutout Dimensions [diameter] | Actuator Type | Switch Function | Termination Style | Voltage Rating - DC | Current Rating (Amps) | Color - Actuator/Cap | Illumination Type, Color | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 125 V | No Marking | -25 °C | 70 °C | 16 mm | Plunger for Cap | On-Mom | PC Pin | 30 V | 3 A | |||
 NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 28 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 28 V | 0.4 VA | Clear | Green/Red LED | 2 VDC |
NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 28 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | PC Pin | 28 V | 0.4 VA | Clear | Green/Red LED | 2.1 VDC |
NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 28 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 28 V | 0.4 VA | Clear | Green/Red LED | 24 V |
NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 125 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 30 V | 3 A | Clear | Green LED | 2 VDC |
NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 28 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 28 V | 0.4 VA | Clear | Green LED | 12 VDC |
 NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 125 V | No Marking | -25 °C | 70 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 30 V | 3 A | White | ||
 NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 28 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 28 V | 0.4 VA | Clear | Amber LED | 12 VDC |
NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 125 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 30 V | 3 A | Clear | Green LED | 24 V |
NKK Switches | 100000 Cycles | 1000000 Cycles | SPDT | Illuminated Standard | Panel Mount Front | Tactile Feedback | IP65 - Dust Tight Water Resistant | 125 V | No Marking | -25 °C | 50 °C | 16 mm | Button Square | On-Mom | Solder Quick Connect - 0.110" (2.8mm) | 30 V | 3 A | Clear | LED Red | 5 VDC |
