EBVW012 Series

Catalog

DC DC CONVERTER 12V 152W

Part	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Type	Current - Output (Max) [Max]	Efficiency	Voltage - Input (Max) [Max]	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Min) [Min]	Control Features	Voltage - Output 1	Mounting Type	Applications	Package / Case	Number of Outputs	Features	Power (Watts)	Supplier Device Package
OmniOn Power™ EBVW012A7B1Z	0.44 in	58.4 mm	11.1 mm	0.9 in	22.9 mm	2.3 in	Isolated Module	12.7 A	95 %	75 V	2250 VDC	85 °C	-40 C	34 V	Active Low Enable	12 V	Through Hole	ITE (Commercial)	8-DIP Module	1	OCP OTP OVP Remote On/Off UVLO	152 W
OmniOn Power™ EBVW012A7B9641Z	0.44 in	58.4 mm	11.3 mm	0.9 in	22.8 mm	2.3 in	Intermediate Bus Converter	12.7 A	95 %	75 V	2250 VDC	85 °C	-40 °C	34 V		12 V	Through Hole	ITE (Commercial)	Eighth Brick	1	OCP OTP OVP Remote On/Off UVLO		Eighth Brick
OmniOn Power™ EBVW012A7B9641Z	0.44 in	58.4 mm	11.3 mm	0.9 in	22.8 mm	2.3 in	Intermediate Bus Converter	12.7 A	95 %	75 V	2250 VDC	85 °C	-40 °C	34 V		12 V	Through Hole	ITE (Commercial)	Eighth Brick	1	OCP OTP OVP Remote On/Off UVLO		Eighth Brick
OmniOn Power™ EBVW012A7B1Z	0.44 in	58.4 mm	11.1 mm	0.9 in	22.9 mm	2.3 in	Isolated Module	12.7 A	95 %	75 V	2250 VDC	85 °C	-40 C	34 V	Active Low Enable	12 V	Through Hole	ITE (Commercial)	8-DIP Module	1	OCP OTP OVP Remote On/Off UVLO	152 W
