833-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 17POS 0.156
| Part | Material - Insulation | Termination Rows | Card Type | Read Out | Contact Material | Number of Positions/Bay/Row [custom] | Contact Finish | Contact Type | Gender | Number of Rows | Color | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Wire Wrap | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Solder | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Right Angle Through Hole | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Solder | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Wire Wrap | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Solder | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Through Hole |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Copper Alloy | 17 | Gold | Cantilever | Female | 1 | Green | Solder | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 125 °C | -40 C | 0.25 Ám | 10 Áin | Right Angle Through Hole |
