IME12 Series

Catalog

SENSOR PROX INDUC 2MM CYL 2M CBL

Part	Shielding	Material - Body	Sensing Distance	Sensing Distance	Termination Style	Ingress Protection	Sensor Type	Output Type	Output Type	Operating Temperature [Min]	Operating Temperature [Max]	Response Frequency	Package / Case	Indicator	Voltage - Supply [Min]	Voltage - Supply [Max]
SICK, Inc. 1040734	Shielded	Plastic	2 mm	0.079 in	Cable Leads	IP67	Inductive	PNP-NO	3	-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. IME12-04BNOZW2S	Shielded	Plastic	4 mm	0.157 in	Cable Leads	IP67	Inductive	3-Wire NPN-NC		-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. 1040760	Shielded	Plastic	4 mm	0.157 in	Connector	IP67	Inductive	3-Wire NPN-NC		-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. 1040787	Shielded	Plastic	8 mm	0.315 in	Connector	IP67	Inductive	3-Wire NPN-NO		-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. 1040764	Unshielded	Nickel-Plated Brass	4 mm	0.157 in	Connector	IP67	Inductive	PNP-NO	3	-25 °C	75 ░C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. 1068256	Shielded	Plastic	8 mm	0.315 in	Cable Leads	IP67	Inductive	2-Wire NC		-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. IME12-02BNOZC0K	Shielded	Plastic	2 mm	0.079 in	Connector	IP67	Inductive	3-Wire NPN-NC		-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. 1058759	Shielded	Plastic	4 mm	0.157 in	Connector	IP67	Inductive	PNP-NO	3	-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. IME12-02BPOZC0K	Shielded	Plastic	2 mm	0.079 in	Connector	IP67	Inductive	PNP-NC	3	-25 °C	75 °C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
SICK, Inc. 1040780	Unshielded	Nickel-Plated Brass	8 mm	0.315 in	Connector	IP67	Inductive	PNP-NO	3	-25 °C	75 ░C	2 kHz	Cylinder Threaded - M12	LED	10 VDC	30 VDC
