PDRB-60 Series

Manufacturer: CUI Inc.

Catalog

AC/DC DIN RAIL SUPPLY 5V 33W

Part	Applications	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Number of Outputs	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Current - Output (Max) [Max]	Power (Watts)	Standard Number	Voltage - Output 1	Approval Agency	Efficiency	Input Type	Voltage - Isolation	DC Voltage - Input (Max) [Max]	Features	DC Voltage - Input (Min) [Min]
CUI Inc. PDRB-60-5	ITE (Commercial)	264 VAC	85 VAC	1	52 mm	2.05 in	92.7 mm	3.65 in	58 mm	2.28 "	6.5 A	33 W	62368-1	5 V	CE cURus	84 %	AC or DC	4000 V	370 V	Adjustable Output Universal Input	120 V
CUI Inc. PDRB-60-48	ITE (Commercial)	264 VAC	85 VAC	1	52 mm	2.05 in	92.7 mm	3.65 in	58 mm	2.28 "	1.25 A	60 W	62368-1	48 V	CE cURus	91 %	AC or DC	4000 V	370 V	Adjustable Output Universal Input	120 V
CUI Inc. PDRB-60-15	ITE (Commercial)	264 VAC	85 VAC	1	52 mm	2.05 in	92.7 mm	3.65 in	58 mm	2.28 "	4 A	60 W	62368-1	15 V	CE cURus	89 %	AC or DC	4000 V	370 V	Adjustable Output Universal Input	120 V
CUI Inc. PDRB-60-12	ITE (Commercial)	264 VAC	85 VAC	1	52 mm	2.05 in	92.7 mm	3.65 in	58 mm	2.28 "	4.5 A	54 W	62368-1	12 V	CE cURus	88 %	AC or DC	4000 V	370 V	Adjustable Output Universal Input	120 V
CUI Inc. PDRB-60-24	ITE (Commercial)	264 VAC	85 VAC	1	52 mm	2.05 in	92.7 mm	3.65 in	58 mm	2.28 "	2.5 A	60 W	62368-1	24 V	CE cURus	90 %	AC or DC	4000 V	370 V	Adjustable Output Universal Input	120 V
