RJ Series
Manufacturer: IDEC
Beta
⌘K
RELAY SOCKETS & HARDWARE FINGERSAFE DIN SOCKET FOR RJ1
| Part | For Use With/Related Products | Number of Positions | Type | Mounting Type | Termination Style | Operate Time | Relay Type | Operating Temperature [Max] | Operating Temperature [Min] | Must Release Voltage | Switching Voltage [Max] | Must Operate Voltage | Approval Agency | Coil Type | Release Time | Load - Max Switching | Contact Form | Contact Rating (Current) | Contact Material | Coil Voltage | Coil Current | Switching Voltage | Features | Termination Style | Coil Resistance | Seal Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 IDEC | RJ Series | 5 | Socket | DIN Rail | Screw Terminal | |||||||||||||||||||||
 IDEC | Through Hole | PC Pin | 15 ms | General Purpose | 70 °C | -40 C | 7.2 VAC | 30 VDC 250 VAC | 19.2 VAC | CE CSA cURus VDE | Non Latching | 10 ms | 30 W 250 VA | DPDT (2 Form C) | 1 A | Silver Nickel (AgNi) | 24 VAC | 0.0375 A | ||||||||
 IDEC | Through Hole | PC Pin | 15 ms | General Purpose | 70 °C | -40 C | 36 VAC | 96 VAC | CE CSA cURus VDE | Non Latching | 10 ms | SPST-NO (1 Form A) | 12 A | Silver Nickel (AgNi) | 120 VAC | 7.5 mA | 250 VAC | |||||||||
 IDEC | Socketable | Plug In | 15 ms | General Purpose | 70 °C | -40 C | 2.4 VDC | 30 VDC 250 VAC | 16.8 VDC | CE CSA cURus VDE | Non Latching | 10 ms | 30 W 250 VA | DPDT (2 Form C) | 1 A | Silver Nickel (AgNi) | 24 VDC | 25.7 mA | Diode Lighted Indicator | |||||||
 IDEC | Socketable | Plug In Quick Connect | 15 ms | General Purpose | 70 °C | -40 C | 72 VAC/DC | 192 VAC | CE CSA cURus VDE | Non Latching | 10 ms | SPDT (1 Form C) | 16 A | Silver Nickel (AgNi) | 240 VAC/DC | 3.7 mA | 30 VDC 250 VAC | 0.187 in 4.7 mm | ||||||||
 IDEC | RJ Series | 8 | Socket | Through Hole | PC Pin | |||||||||||||||||||||
 IDEC | Socketable | Plug In | 15 ms | General Purpose | 70 °C | -40 C | 36 VAC | 96 VAC | CE CSA cURus VDE | Non Latching | 10 ms | DPDT (2 Form C) | 8 A | Silver Nickel (AgNi) | 120 VAC | 7.4 mA | 250 VAC | Lighted Indicator | ||||||||
 IDEC | Socketable | Plug In | 20 ms | General Purpose | 70 °C | -40 C | 1.2 VDC | 8.4 VDC | CE CSA cURus VDE | Non Latching | 20 ms | DPDT (2 Form C) | 8 A | Silver Nickel (AgNi) | 12 VDC | 44.2 mA | 250 VAC | Diode | 271 Ohms | |||||||
IDEC | Through Hole | PC Pin | 15 ms | General Purpose | 70 °C | -40 C | 36 VAC | 96 VAC | CE CSA cURus VDE | Non Latching | 10 ms | DPDT (2 Form C) | 8 A | Silver Nickel (AgNi) | 120 VAC | 7.5 mA | 125 VDC 250 VAC | 6.4 kOhms | ||||||||
IDEC | Through Hole | PC Pin | 15 ms | General Purpose | 70 °C | -40 C | 72 VAC/DC | 192 VAC | CE CSA cURus VDE | Non Latching | 10 ms | SPDT (1 Form C) | 12 A | Silver Nickel (AgNi) | 240 VAC/DC | 3.7 mA | 125 VDC 250 VAC | 25.57 kOhms | Sealed - Flux Protection |
