831-41 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 28POS 0.079 GOLD PCB

...

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Material	Insulation Material	Contact Shape	Connector Type	Number of Rows	Number of Positions Loaded	Contact Finish - Mating	Contact Finish - Post	Contact Length - Post	Contact Length - Post	Mounting Type	Fastening Type	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Contact Type	Termination	Insulation Height	Insulation Height	Current Rating (Amps)	Insulation Color	Insulation Height [z]	Insulation Height [z]
Mill-Max Manufacturing Corp. 831-41-028-10-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin	0.125 in	3.18 mm	Through Hole	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	28	Female Socket	Solder	0.165 in	4.2 mm	3 A	Black
Mill-Max Manufacturing Corp. 831-41-043-10-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin	0.125 in	3.18 mm	Through Hole	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	43	Female Socket	Solder	0.165 in	4.2 mm	3 A	Black
Mill-Max Manufacturing Corp. 831-41-012-30-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin			Surface Mount	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	12	Female Socket	Solder			3 A	Black	0.228 "	5.8 mm
Mill-Max Manufacturing Corp. 831-41-020-10-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin	0.125 in	3.18 mm	Through Hole	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	20	Female Socket	Solder	0.165 in	4.2 mm	3 A	Black
Mill-Max Manufacturing Corp. 831-41-040-20-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin	0.14 in	3.56 mm	Right Angle Through Hole	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	40	Female Socket	Solder			3 A	Black	0.079 in	2 mm
Mill-Max Manufacturing Corp. 831-41-024-30-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin			Surface Mount	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	24	Female Socket	Solder			3 A	Black	0.228 "	5.8 mm
Mill-Max Manufacturing Corp. 831-41-032-10-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin	0.125 in	3.18 mm	Through Hole	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C		Female Socket	Solder	0.165 in	4.2 mm	3 A	Black
Mill-Max Manufacturing Corp. 831-41-019-30-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin			Surface Mount	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	19	Female Socket	Solder			3 A	Black	0.228 "	5.8 mm
Mill-Max Manufacturing Corp. 831-41-049-10-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin	0.125 in	3.18 mm	Through Hole	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	49	Female Socket	Solder	0.165 in	4.2 mm	3 A	Black
Mill-Max Manufacturing Corp. 831-41-035-30-001000	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Receptacle	1	All	Gold	Tin			Surface Mount	Push-Pull	0.079 "	2 mm	UL94 V-0	0.25 µm	10 µin	-55 C	125 °C	35	Female Socket	Solder			3 A	Black	0.228 "	5.8 mm
