K42X-E9P Series
Manufacturer: Kycon, Inc.
Beta
⌘K
CONN D-SUB PLUG 9POS R/A SLDR
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Material | Voltage Rating | Color | Backset Spacing | Backset Spacing | Contact Finish | Features | Material Flammability Rating | Shell Material, Finish | Contact Finish Thickness | Mounting Type | Contact Type | Number of Positions | Connector Style | Termination | Current Rating (Amps) | Connector Type | Flange Feature | Number of Rows [custom] | Shell Size, Connector Layout | Flange Feature | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kycon, Inc. | -55 C | 105 ░C | Polybutylene Terephthalate (PBT) | Brass | 30 VDC | Black | 8.08 mm | 0.318 " | Gold | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | Nickel Plated Steel | Flash | Right Angle Through Hole | Signal | 9 | D-Sub - Stacked | Solder | 1.2 A | Plug Male Pins | 4-40 Mating Side Female Screwlock | 2 | 1 | |||
 Kycon, Inc. | -55 C | 105 ░C | Polybutylene Terephthalate (PBT) Glass Filled | Brass Phosphor Bronze | 30 VDC | Black | 8.08 mm | 0.318 " | Gold | Board Lock Grounding Indents Mounting Brackets | UL94 V-0 | Nickel Plated Steel | Right Angle Through Hole | Signal | 9 | D-Sub - Stacked | Solder | 2 A | Plug Male Pins Receptacle Female Sockets | Housing/Shell | 2 | 1 | 4-40 | 30 Áin | 0.76 Ám |
