0881100.F Series

FUSE 75V HA F/A NANO2 Pb-Free 100A

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

FUSE 75V HA F/A NANO2 Pb-Free 100A

Part	Melting I²t	Voltage Rating - DC	Package / Case	Breaking Capacity @ Rated Voltage	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Fuse Type	DC Cold Resistance	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Mounting Type
Littelfuse/Commercial Vehicle Products 0881100.URF	6900	75 V	2-SMD J-Lead	1.5 kA	100 A	100 °C	-55 °C	Board Mount	0.45 Ohms	0.268 in	10 mm	11.2 mm	0.394 in	0.441 in	6.8 mm	Surface Mount

Catalog

FUSE 75V HA F/A NANO2 Pb-Free 100A

Key Features

• Available with ampere ratings of 70 A, 80 A, or 100 A

• High interrupting rating - 1500A@75VDC

• Faster opening time response for 200 % OL current

• Robust and solderless fuse design

• Surface mountable high-current fuse

Description

The 881F Series NANO²® fuse is a relatively small sized, high-current, surface-mount fuse which provides overcurrent protection for applications of high operating current in a limited space. This is the faster opening version of the original 881 Series which offers faster opening response during current overload conditions, protecting downstream components from getting damaged. Such applications are mostly served today through a single large-sized high-current industrial type fuse or in some cases, parallel configuration of lower amperage SMD fuses. The 881F Series fuses provide the option of a single fuse solution for protection for such application requirements.
