RAYCHEM ATUM Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
HEAT SHRINK TUBING & SLEEVES ATUM-32/8-0-85MM
| Part | Inner Diameter - Recovered [diameter] | Inner Diameter - Recovered [diameter] | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Max] | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Max] | Color | Recovered Wall Thickness | Recovered Wall Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Features | Shelf Life | Shrinkage Ratio | Length [x] | Length [x] | Length [x] | Type | Material | Shrink Temperature | Inner Diameter - Supplied [diameter] | Inner Diameter - Supplied [diameter] | Inner Diameter - Recovered | Inner Diameter - Recovered | Spool Size [custom] | Spool Size [custom] | Length | Length | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 8 mm | 0.315 in | 0 °C | 35 °C | 32 °F | 95 °F | Black | 2.54 mm | 0.1 in | -55 C | 110 °C | Adhesive Lined Fluid Resistant | 60 Months | 4 to 1 | 3.35 in | 0.279 ft | 85 mm | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 1.26 in | 32 mm | ||||||||
 TE Connectivity AMP Connectors | 0 °C | 35 °C | 32 °F | 95 °F | Black | 0.99 mm | 0.039 in | -55 C | 110 °C | 3 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.118 " | 3 mm | 0.039 in | 0.99 mm | |||||||||||||
 TE Connectivity AMP Connectors | 0 °C | 35 °C | 32 °F | 95 °F | Black | 0.99 mm | 0.039 in | -55 C | 110 °C | Adhesive Lined Flame Retardant Fluid Resistant | 60 Months | 3 to 1 | Tubing Semi-Flexible | Polyolefin | 80 °C | 0.118 " | 3 mm | 0.039 in | 0.99 mm | 150 m | 492.1 ft | Enter Number of Meters in Order Quantity | ||||||||
TE Connectivity AMP Connectors | 3 mm | 0.118 in | 0 °C | 35 °C | 32 °F | 95 °F | Black | -55 C | 110 °C | 4 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.472 in | 11.99 mm | |||||||||||||||
TE Connectivity AMP Connectors | 5.99 mm | 0.236 in | 0 °C | 35 °C | 32 °F | 95 °F | Black | 2.25 mm | 0.088 in | -55 C | 110 °C | Adhesive Lined Fluid Resistant | 60 Months | 3 to 1 | Tubing Semi-Flexible | Polyolefin | 80 °C | Enter Number of Meters in Order Quantity | 492.1 ft | 150 m | ||||||||||
TE Connectivity AMP Connectors | 3.99 mm | 0.157 " | 0 °C | 35 °C | 32 °F | 95 °F | Black | 1.78 mm | 0.07 in | -55 C | 110 °C | Adhesive Lined Fluid Resistant | 60 Months | 3 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.472 in | 11.99 mm | 0.098 ' | 0.03 m | 1.18 " | ||||||||
 TE Connectivity AMP Connectors | 2.01 mm | 0.079 in | 0 °C | 35 °C | 32 °F | 95 °F | Red | 0.99 mm | 0.039 in | -55 C | 110 °C | Adhesive Lined Flame Retardant Fluid Resistant | 60 Months | 3 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.236 in | 5.99 mm | 3.28 ft 820.2 ' | 1 m 250 m | |||||||||
 TE Connectivity AMP Connectors | 0 °C | 35 °C | 32 °F | 95 °F | Black | 0.3 mm | 0.012 in | -55 C | 110 °C | 3 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.118 " | 3 mm | 0.039 in | 0.99 mm | |||||||||||||
 TE Connectivity AMP Connectors | 5.99 mm | 0.236 in | 0 °C | 35 °C | 32 °F | 95 °F | Clear | 2.25 mm | 0.088 in | -55 C | 110 °C | Adhesive Lined Fluid Resistant | 60 Months | 3 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.748 in | 19 mm | Enter Number of Meters in Order Quantity | 3.28 ft 492.1 ft | 1 m 150 m | ||||||||
 TE Connectivity AMP Connectors | 0 °C | 35 °C | 32 °F | 95 °F | Black | -55 C | 110 °C | 4 to 1 | Tubing Semi-Flexible | Polyolefin (PO) Irradiated | 80 °C | 0.157 " | 3.99 mm | 0.039 in | 0.99 mm |
