D4N-9B2 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SWITCH SNAP ACT DPST-NC 3A 240V
| Part | Current Rating (Amps) | Features | Mechanical Life | Ingress Protection | Switch Function | Operating Force | Actuator Type | Circuit | Voltage Rating - DC | Voltage Rating - AC | Pretravel | Mounting Type | Overtravel | Differential Travel | Release Force | Termination Style | Electrical Life | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 3 A 270 mA | Metal Lever Resin Roller | 15000000 Cycles | IP67 - Dust Tight Waterproof | On-Mom | 459 gf | Side Rotary Adjustable Roller | DPST-NC | 250 V | 240 V | 18 ° | Chassis Mount | 40 ° | 14 ° | 41 gf | Connector | 300000 Cycles | 70 °C | -30 ░C |
