042820 Series

Manufacturer: Molex

Catalog

MINIFIT SR HDR ASSY 125 2 CKT TI

Part	Material Flammability Rating	Insulation Color	Number of Rows	Contact Finish - Post	Insulation Height [z]	Insulation Height	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Contact Type	Contact Material	Fastening Type	Number of Positions Loaded	Style	Applications	Insulation Material	Connector Type	Shrouding	Mounting Type	Termination	Contact Length - Post	Contact Length - Post	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Shape	Contact Finish - Mating	Number of Positions
Molex 0428202332
Molex 0428203242	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.327 "	8.3 mm	2.54 µm	100 µin	Rectangular
Molex 0428205234	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.201 in	5.11 mm	2.54 µm	100 µin	Rectangular	Silver
Molex 0428202342
Molex 0428204222	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.201 in	5.11 mm	2.54 µm	100 µin	Rectangular		4
Molex 0428206232	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.201 in	5.11 mm	2.54 µm	100 µin	Rectangular		6
Molex 0428203232	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.201 in	5.11 mm	2.54 µm	100 µin	Rectangular
Molex 0428203234	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.201 in	5.11 mm	2.54 µm	100 µin	Rectangular	Silver
Molex 0428204244	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.327 "	8.3 mm	2.54 µm	100 µin	Rectangular	Silver	4
Molex 0428202222	UL94 V-0	Black	1	Tin	0.421 in	10.7 mm	2.54 çm	100 çin	10 mm	0.394 in	Male Blade	Copper Zirconium Alloy	Locking Ramp	All	Board to Cable/Wire	Automotive General Purpose Industrial Medical Telecommunications	Glass Filled Nylon 4/6 Polyamide (PA46)	Header	Shrouded - 4 Wall	Through Hole Right Angle	Solder	0.201 in	5.11 mm	2.54 µm	100 µin	Rectangular		2
