CS11028 Series

Catalog

SWITCH TACTILE SPST-NO 0.05A 50V

Part	Actuator Material	Switch Travel	Operating Temperature [Max]	Operating Temperature [Min]	Termination Style	Contact Rating @ Voltage	Actuator Type	Illumination	Outline [x]	Outline [y]	Actuator Height off PCB, Vertical	Mounting Type	Circuit	Operating Force	Switch Function	Actuator Orientation
CIT Relay and Switch CS11028.0F260	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	Gull Wing	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8 mm	Surface Mount	SPST-NO	260 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.5F100J	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	J Lead	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8.5 mm	Surface Mount	SPST-NO	100 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.5F100	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	Gull Wing	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8.5 mm	Surface Mount	SPST-NO	100 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.0F260J	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	J Lead	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8 mm	Surface Mount	SPST-NO	260 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.5F260J	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	J Lead	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8.5 mm	Surface Mount	SPST-NO	260 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.5F260	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	Gull Wing	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8.5 mm	Surface Mount	SPST-NO	260 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.0F100J	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	J Lead	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8 mm	Surface Mount	SPST-NO	100 gf	Off-Mom	Top Actuated
CIT Relay and Switch CS11028.5F160J	Polyamide (PA46) Nylon 4/6	0.25 mm	85 °C	-40 C	J Lead	0.05 A 50 VDC	Plunger for Cap	Non-Illuminated	6 mm	6 mm	8.5 mm	Surface Mount	SPST-NO	160 gf	Off-Mom	Top Actuated
