PV4F23011 Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH PUSHBUTTON SPDT 2A 24V
| Part | Electrical Life | Mechanical Life | Termination Style | Type | Illumination Type, Color | Voltage Rating - DC | Current Rating (Amps) | Ingress Protection | Actuator Type | Mounting Type | Circuit | Panel Cutout Dimensions [diameter] | Switch Function | Color - Actuator/Cap | Operating Temperature [Max] | Operating Temperature [Min] | Actuator Marking | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Anti-Vandal Illuminated | Green LED | 24 V | 2 A | IP65 - Dust Tight Water Resistant | Button Flush Round | Panel Mount Front | SPDT | 19 mm | On-On | Black | 55 °C | -20 ░C | No Marking | 12 VDC |
 E-Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Anti-Vandal Illuminated | Blue LED | 24 V | 2 A | IP65 - Dust Tight Water Resistant | Button Flush Round | Panel Mount Front | SPDT | 19 mm | On-On | Black | 55 °C | -20 ░C | No Marking | 24 V |
