MAX710 Series

3.3V/5V or Adjustable, Step-Up Step-Down DC-DC Converters

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

3.3V/5V or Adjustable, Step-Up Step-Down DC-DC Converters

Part	Package / Case	Package / Case	Function	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package	Voltage - Input (Max) [Max]	Topology	Number of Outputs	Current - Output	Output Configuration	Mounting Type	Voltage - Output (Min/Fixed)	Number of Bits	Features	Number of Inputs	Input Type	Outputs and Type	Outputs and Type	Board Type	Supplied Contents	Contents	Main Purpose	Voltage - Output	Voltage - Input [Max]	Voltage - Input [Min]	Utilized IC / Part	Regulator Topology	Secondary Attributes	Type
Analog Devices Inc./Maxim Integrated MAX710ESE+	16-SOIC	0.154 in 3.9 mm	Step-Down Step-Up	1.8 V	85 C	-40 ¯C	16-SOIC	11 V	Boost Buck	1	1.1 A	Positive	Surface Mount	3.3 V 5 V
Analog Devices Inc./Maxim Integrated MAX710ESE	16-SOIC	0.154 in 3.9 mm	Step-Down Step-Up	1.8 V	85 C	-40 ¯C	16-SOIC	11 V	Boost Buck	1	1.1 A	Positive	Surface Mount	3.3 V 5 V
Analog Devices Inc./Maxim Integrated MAX710C/D			Step-Down Step-Up	1.8 V	70 °C	0 °C		11 V	Boost Buck	1	1.1 A	Positive		3.3 V 5 V
Analog Devices Inc./Maxim Integrated MAX71071+T	10-TFSOP 10-MSOP (0.118" 3.00mm Width)				85 °C	-40 C	10-uMAX/uSOP						Surface Mount		24	Temperature Sensor	2	Differential
Analog Devices Inc./Maxim Integrated MAX71071+	10-TFSOP 10-MSOP (0.118" 3.00mm Width)				85 °C	-40 C	10-uMAX/uSOP						Surface Mount		24	Temperature Sensor	2	Differential
Analog Devices Inc./Maxim Integrated MAX710ESE+T	16-SOIC	0.154 in 3.9 mm	Step-Down Step-Up	1.8 V	85 C	-40 ¯C	16-SOIC	11 V	Boost Buck	1	1.1 A	Positive	Surface Mount	3.3 V 5 V
Analog Devices Inc./Maxim Integrated MAX710EVKIT											250 mA								1	1 Non-Isolated Output Non-Isolated	Fully Populated	Board(s)	Board(s)	DC/DC Step Up	3.3 V 5 V	11 V	1.8 V	MAX710	Boost
Analog Devices Inc./Maxim Integrated MAX71020AEVK1#			Energy/Power Meter																			Board(s)	Board(s)					MAX71020		SPI Interface(s)	Power Management

Catalog

3.3V/5V or Adjustable, Step-Up Step-Down DC-DC Converters

Description

The MAX710/MAX711 integrate a step-up DC-DC converter with a linear regulator to provide step-up/down voltage conversion. They are optimized for battery applications where the input varies above and below the regulated output voltage. They have an input range from +1.8V to +11V. Typical efficiency when boosting battery inputs is 85%.The MAX710/MAX711 can be configured for minimum noise or optimum efficiency. Shutdown control turns off the part completely, disconnecting the input from the output (ISHDN= 0.2µA). Standby control turns off only the step-up converter and leaves the low-power linear regulator active (IQ= 7µA).The MAX710 has a preset 3.3V or 5V output voltage. The MAX711 has an adjustable output that can be set from +2.7V to +5.5V with two resistors. Both devices come in 16-pin narrow SO packages.Applications2- to 4-Cell AA Alkaline Handheld Equipment2-, 3-, and 4-Cell Battery-Powered Equipment3.3V and Other Low-Voltage SystemsBattery-Powered Devices with AC Input AdaptersDigital Still CamerasSingle-Cell, Lithium-Powered Portable Devices
