ZT028 Series
Manufacturer: Mallory Sonalert Products Inc.
Beta
⌘K
BUZZER PIEZO 24V 30.74MM PNL MNT
| Part | Port Location | Size / Dimension [diameter] | Size / Dimension [diameter] | Sound Pressure Level (SPL) | Ingress Protection | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Height - Seated (Max) | Height - Seated (Max) [Max] [z] | Operating Mode | Input Type | Termination | Current - Supply | Voltage - Rated | Technology | Driver Circuitry | Frequency | Voltage Range [Min] | Voltage Range [Max] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mallory Sonalert Products Inc. | Top | 1.21 in | 30.74 mm | 85 dB | NEMA 12 NEMA 3R NEMA 4X | cUL UL | -30 ░C | 65 °C | 56.75 mm | 2.234 in | Single Tone Visual Indicator | DC | Terminal Block | 50 mA | 24 VDC | Piezo | Indicator Internally Driven | 3.9 kHz | 20 VDC | 28 V | Panel Mount |
