SN74HC126A Series

4-ch, 2-V to 6-V buffers with 3-state outputs

Catalog

4-ch, 2-V to 6-V buffers with 3-state outputs

Part	Mounting Type	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Number of Elements	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Logic Type	Number of Bits per Element	Voltage - Supply [Min]	Voltage - Supply [Max]	Package / Case [x]	Package / Case [y]	Package / Case	Supplier Device Package	Package / Case [custom]	Package / Case [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case
Texas Instruments SN74HC126DRG4	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V	0.154 in	3.9 mm	14-SOIC
Texas Instruments SN74HC126PWT	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V			14-TSSOP	14-TSSOP	0.173 "	4.4 mm
Texas Instruments CD74HC126M	Surface Mount	3-State			4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V	0.154 in	3.9 mm	14-SOIC				125 °C	-55 °C
Texas Instruments SN74HC126ANSR	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V	0.209 "	5.3 mm	14-SOIC	14-SO
Texas Instruments CD74HC126E	Through Hole	3-State			4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V	0.3 "	7.62 mm	14-DIP				125 °C	-55 °C
Texas Instruments SN74HC126APWR	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V			14-TSSOP	14-TSSOP	0.173 "	4.4 mm
Texas Instruments CD74HC126MT	Surface Mount	3-State			4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V	0.154 in	3.9 mm	14-SOIC				125 °C	-55 °C
Texas Instruments SN74HC126PWR	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V			14-TSSOP	14-TSSOP	0.173 "	4.4 mm
Texas Instruments SN74HC126NSR	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V	0.209 "	5.3 mm	14-SOIC	14-SO
Texas Instruments SN74HC126DBR	Surface Mount	3-State	85 °C	-40 °C	4	7.8 mA	7.8 mA	Buffer Non-Inverting	1	2 V	6 V			14-SSOP	14-SSOP					5.3 mm	0.209 "

Catalog

4-ch, 2-V to 6-V buffers with 3-state outputs

Key Features

• Buffered inputsWide operating voltage range: 2 V to 6 VWide operating temperature range: -55°C to +125°CSupports fanout up to 10 LSTTL loadsSignificant power reduction compared to LSTTL logic ICsBuffered inputsWide operating voltage range: 2 V to 6 VWide operating temperature range: -55°C to +125°CSupports fanout up to 10 LSTTL loadsSignificant power reduction compared to LSTTL logic ICs

Description

This device contains four independent buffers with 3-state outputs. Each gate performs the Boolean function Y = A in positive logic. This device contains four independent buffers with 3-state outputs. Each gate performs the Boolean function Y = A in positive logic.
