505568 Series
Manufacturer: Molex
Beta
⌘K
1.25MM PITCH, MICRO-LOCK PLUS PCB HEADER, SINGLE ROW, VERTICAL, SURFACE MOUNT, TIN-BISMUTH PLATING, POSITIVE LOCK, 15 CIRCUITS, WITH PICK-AND-PLACE TAPE, BLACK
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Mated Stacking Heights | Applications | Contact Finish - Post | Insulation Color | Style | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Number of Positions Loaded | Contact Material | Current Rating (Amps) | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Material Flammability Rating | Shrouding | Contact Shape | Features | Insulation Material | Number of Positions | Fastening Type | Mounting Type | Contact Type | Insulation Height | Insulation Height | Connector Type | Pitch - Mating | Pitch - Mating | Voltage Rating | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 39.4 çin | 1 çm | 7.4 mm | Automotive General Purpose Industrial | Tin | Black | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | 39.4 µin | 1 µm | UL94 V-0 | Shrouded - 4 Wall | Square | Solder Retention | Glass Filled Nylon Polyamide (PA) | 15 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | |||
 Molex | Gold | Black | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 9 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | Gold | 0.38 µm | 15 µin | ||||||
 Molex | 39.4 çin | 1 çm | 7.4 mm | Automotive General Purpose Industrial | Tin | Natural | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | 39.4 µin | 1 µm | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 13 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | |||
 Molex | 39.4 çin | 1 çm | 7.4 mm | Automotive General Purpose Industrial | Tin | Natural | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | 39.4 µin | 1 µm | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 14 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | |||
 Molex | Gold | Black | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 7 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | Gold | 0.38 µm | 15 µin | ||||||
 Molex | Tin | Green | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | 39.4 µin | 1 µm | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 15 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | |||||||
 Molex | 39.4 çin | 1 çm | 7.4 mm | Automotive General Purpose Industrial | Tin | Black | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | 39.4 µin | 1 µm | UL94 V-0 | Shrouded - 4 Wall | Square | Solder Retention | Glass Filled Nylon Polyamide (PA) | 11 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | |||
 Molex | Gold | Black | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 9 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | Gold | 0.76 Ám | 30 Áin | ||||||
 Molex | Gold | Black | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 8 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC | Gold | 0.76 Ám | 30 Áin | ||||||
 Molex | 39.4 çin | 1 çm | 7.4 mm | Automotive General Purpose Industrial | Tin | Red | Board to Cable/Wire | Solder | -40 C | 105 ░C | 1 | All | Brass | Varies by Wire Gauge | 39.4 µin | 1 µm | UL94 V-0 | Shrouded - 4 Wall | Square | Pick and Place Solder Retention | Glass Filled Nylon Polyamide (PA) | 5 | Push-Pull | Surface Mount | Male Pin | 0.165 in | 4.2 mm | Header | 0.049 in | 1.25 mm | 50 VAC |
