895-106 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 106POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions | Gender | Contact Type | Color | Read Out | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Pitch | Pitch | Number of Rows [custom] | Contact Material | Termination | Mounting Type | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Gold | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | Gold | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | 0.128 " | 3.25 mm | Gold | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Right Angle Through Hole | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Gold | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder Eyelet(s) | Through Hole | Non Specified - Dual Edge | M3 Threaded Insert Top Mount Opening | Gold | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Wire Wrap | Through Hole | Non Specified - Dual Edge | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Gold |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 106 | Female | Cantilever | Black | Dual | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 53 | 0.1 " | 2.54 mm | 2 | Copper Alloy | Solder | Through Hole | Non Specified - Dual Edge | 0.156 " | 3.96 mm | Gold |
