842-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 23POS 0.100
| Part | Termination Rows | Material - Insulation | Read Out | Card Type | Pitch | Pitch | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Color | Contact Finish | Contact Material | Number of Rows | Gender | Mounting Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Wire Wrap | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | Flush Mount M3 Threaded Insert Top Opening | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Right Angle Through Hole | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Wire Wrap | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder Eyelet(s) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Wire Wrap | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | Flush Mount M3 Threaded Insert Top Opening | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | Cantilever | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Single | Non Specified - Single Edge | 0.1 " | 2.54 mm | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 23 | 0.25 Ám | 10 Áin | 23 | Green | Gold | Copper Alloy | 1 | Female | Through Hole | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Cantilever |
