D38999/26WD Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN PLUG FMALE 18POS GOLD CRIMP
| Part | Shell Material | Features | Primary Material | Voltage Rating | Voltage Rating | Fastening Type | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Shell Finish | Connector Type | Mounting Type | Qualification | Number of Positions | Applications | Ingress Protection | Termination | Shielding | Shell Size - Insert [Max] | Shell Size - Insert [Min] | Orientation | Color | Insert Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Grade | Contact Material | Current Rating (Amps) | Shell Size, MIL | Contact Type | Housing Color | Type | Contact Size | Note | Contact Shape |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors | Aluminum | Coupling Nut | Metal | 600 VAC | 850 VDC | Threaded | Gold | -65 ░C | 175 °C | Olive Drab Cadmium | Plug Female Sockets | Free Hanging (In-Line) | MIL-DTL-38999 Series III | 18 | Aviation Communication Systems Industrial Military | Environment Resistant | Crimp | Shielded | 18 | 15 | B | Olive Drab | Thermoplastic | 50 µin | 1.27 µm | Military | Copper Alloy | ||||||||
 TE Connectivity AMP Connectors | Aluminum | Self Locking | Metal | Threaded | Gold | -65 ░C | 175 °C | Olive Drab Cadmium | Plug Male Pins | Free Hanging (In-Line) | MIL-DTL-38999 Series III | 37 | Aviation Communication Systems Industrial Military | Environment Resistant | Crimp | Shielded | 35 | 15 | N (Normal) | Olive Drab | Thermoplastic | 50 µin | 1.27 µm | Military | Copper Alloy | 5 A | D | ||||||||
 TE Connectivity AMP Connectors | Aluminum | Self Locking | Metal | Threaded | Gold | -65 ░C | 175 °C | Olive Drab Cadmium | Plug Male Pins | Free Hanging (In-Line) | MIL-DTL-38999 Series III | 19 | Aviation Communication Systems Industrial Military | Environment Resistant | Crimp | Shielded | 19 | 15 | N (Normal) | Olive Drab | Thermoplastic | 50 µin | 1.27 µm | Military | Copper Alloy | 7.5 A | D | ||||||||
TE Connectivity AMP Connectors | Aluminum | Coupling Nut | Metal | Threaded | -65 ░C | 175 °C | Cadmium | Plug Housing | Free Hanging (In-Line) | MIL-DTL-38999 Series III | 15 | Environment Resistant | Shielded | 15 | 15 | N (Normal) | Thermoplastic | Military | D | Crimp | Olive Drab | For Female Sockets | 16 20 | Contacts Not Included | Circular |
