2349820 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
PCIEG4,SMT,V,98P,15U,ML,HT,OEW
| Part | Number of Positions | Read Out | Features | Number of Rows | Termination | Pitch [x] | Pitch [x] | Contact Type | Contact Finish | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows | Material - Insulation | Card Type | Card Thickness | Card Thickness | Color | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Contact Material | Gender | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 98 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 15 µin | 0.38 µm | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | 38 | 11 | Copper Alloy | Female | |||
 TE Connectivity Raychem Cable Protection | 164 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | Copper Alloy | Female | Flash | 71 | 11 | ||||
 TE Connectivity Raychem Cable Protection | 98 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | 38 | 11 | Copper Alloy | Female | Flash | ||||
 TE Connectivity Raychem Cable Protection | 98 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 30 Áin | 0.76 Ám | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | 38 | 11 | Copper Alloy | Female | |||
 TE Connectivity Raychem Cable Protection | 164 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 30 Áin | 0.76 Ám | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | Copper Alloy | Female | 71 | 11 | |||
 TE Connectivity Raychem Cable Protection | 164 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 30 Áin | 0.76 Ám | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | Copper Alloy | Female | 71 | 11 | |||
 TE Connectivity Raychem Cable Protection | 98 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 15 µin | 0.38 µm | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | 38 | 11 | Copper Alloy | Female | |||
 TE Connectivity Raychem Cable Protection | 98 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 15 µin | 0.38 µm | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | 38 | 11 | Copper Alloy | Female | |||
 TE Connectivity Raychem Cable Protection | 164 | Dual | Board Guide Locking Ramp | 2 | Solder | 0.039 in | 1 mm | Cantilever | Gold | Surface Mount | 15 µin | 0.38 µm | 85 °C | -40 °C | 2 | Liquid Crystal Polymer (LCP) | PCI Express™ | 0.062 in | 1.57 mm | Black | Copper Alloy | Female | 71 | 11 | |||
TE Connectivity Raychem Cable Protection | 98 | Gold | Surface Mount | Flash |
