GPFM115 Series
Manufacturer: SL POWER / Advanced Energy
Beta
⌘K
AC/DC CONVERTER 24V 80W
| Part | Minimum Load Required | Approval Agency | Features | Current - Output 1 | Type | Mounting Type | Power (Watts) | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Voltage - Output 1 | Number of Outputs | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SL POWER / Advanced Energy | CE cURus TUV | Adjustable Output PFC Remote Sense Universal Input | 3.3 A | Open Frame | Chassis Mount | 80 W 115 W | 1.5 in | 38.1 mm | 3.3 " | 83.8 mm | 5.25 in | 133.4 mm | 50 °C | 0 °C | Medical | 24 V | 1 | 81 % | |
SL POWER / Advanced Energy | CE cURus TUV | Adjustable Output PFC Remote Sense Universal Input | 2.9 A | Open Frame | Chassis Mount | 80 W 115 W | 1.5 in | 38.1 mm | 3.3 " | 83.8 mm | 5.25 in | 133.4 mm | 50 °C | 0 °C | Medical | 28 V | 1 | 81 % | |
 SL POWER / Advanced Energy | CE cURus TUV | Adjustable Output PFC Remote Sense Universal Input | 12 A | Open Frame | Chassis Mount | 80 W 115 W | 1.5 in | 38.1 mm | 3.3 " | 83.8 mm | 5.25 in | 133.4 mm | 50 °C | 0 °C | Medical | 5.1 V | 1 | 81 % | |
 SL POWER / Advanced Energy | CE cURus TUV | Adjustable Output PFC Remote Sense Universal Input | 1.7 A | Open Frame | Chassis Mount | 80 W 115 W | 1.5 in | 38.1 mm | 3.3 " | 83.8 mm | 5.25 in | 133.4 mm | 50 °C | 0 °C | Medical | 48 V | 1 | 81 % | |
SL POWER / Advanced Energy | CE cURus TUV | Adjustable Output PFC Remote Sense Universal Input | 4.8 A | Open Frame | Chassis Mount | 80 W 115 W | 1.5 in | 38.1 mm | 3.3 " | 83.8 mm | 5.25 in | 133.4 mm | 50 °C | 0 °C | Medical | 24 V | 1 | 81 % | |
 SL POWER / Advanced Energy | CE cURus TUV | Adjustable Output PFC Remote Sense Universal Input | 6.7 A | Open Frame | Chassis Mount | 80 W 115 W | 1.5 in | 38.1 mm | 3.3 " | 83.8 mm | 5.25 in | 133.4 mm | 50 °C | 0 °C | Medical | 12 V | 1 | 81 % |
