D2864 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN IC DIP SOCKET 64POS GOLD
| Part | Material Flammability Rating | Contact Resistance | Current Rating (Amps) | Termination Post Length [x] | Termination Post Length [x] | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Features | Contact Finish - Post | Termination | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Type [custom] | Type [custom] | Type | Housing Material | Contact Material - Mating | Pitch - Mating | Pitch - Mating | Number of Positions or Pins (Grid) [x] | Number of Positions or Pins (Grid) | Number of Positions or Pins (Grid) [y] | Contact Finish Thickness - Mating | Pitch - Post | Pitch - Post | Contact Material - Post [custom] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | UL94 V-0 | 10 mOhm | 1 A | 3.2 mm | 0.126 in | Gold | -55 C | 125 °C | Open Frame | Tin | Solder | 5 µm | 196.9 µin | 15.24 mm | 0.6 in | DIP | Plastic | Beryllium Copper | 0.1 " | 2.54 mm | 2 | 64 | 32 | Flash | 0.1 in | 2.54 mm | Brass | Through Hole |
