638-M15 Series
Manufacturer: EDAC Inc.
Beta
⌘K
638M SERIES VERTICAL D-SUB RECEP
| Part | Contact Material | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Type | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Number of Rows [custom] | Contact Finish | Features | Connector Type | Connector Style | Current Rating (Amps) | Material Flammability Rating | Flange Feature | Shell Material, Finish | Mounting Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Termination | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | Flash | (DE E) High Density | 1 | 3 | Gold | Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Board Side (4-40) | Nickel Plated Steel | Free Hanging (In-Line) | 15 | ||||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | (DE E) High Density | 1 | 3 | Gold | Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Housing/Shell (Unthreaded) | Nickel Plated Steel | Free Hanging (In-Line) | 15 | 30 Áin | 0.76 Ám | |||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | (DE E) High Density | 1 | 3 | Gold | Board Lock Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | 4-40 | Nickel Plated Steel | Through Hole | 15 | 15 µin | 0.38 µm | Solder | ||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | (DE E) High Density | 1 | 3 | Gold | Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Board Side (4-40) | Free Hanging (In-Line) | 15 | 15 µin | 0.38 µm | ||||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | Flash | (DE E) High Density | 1 | 3 | Gold | Board Lock Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Board Side (4-40) | Nickel Plated Steel | Free Hanging (In-Line) | 15 | ||||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | Flash | (DE E) High Density | 1 | 3 | Gold | Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Housing/Shell (Unthreaded) | Nickel Plated Steel | Free Hanging (In-Line) | 15 | ||||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | Flash | (DE E) High Density | 1 | 3 | Gold | Board Lock Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Board Side (4-40) | Free Hanging (In-Line) | 15 | |||||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | (DE E) High Density | 1 | 3 | Gold | Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Housing/Shell | Nickel Plated Steel | Free Hanging (In-Line) | 15 | 30 Áin | 0.76 Ám | 4-40 | ||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | (DE E) High Density | 1 | 3 | Gold | Board Lock Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | 4-40 | Through Hole | 15 | 15 µin | 0.38 µm | Solder | |||
 EDAC Inc. | Copper Alloy | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Black | Signal | Flash | (DE E) High Density | 1 | 3 | Gold | Shielded | Receptacle Female Sockets | D-Sub High Density | 5 A | UL94 V-0 | Housing/Shell | Free Hanging (In-Line) | 15 | 4-40 |
