396-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 36POS 0.125
| Part | Material - Insulation | Termination Rows | Number of Positions | Number of Rows | Mounting Type | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Material | Contact Finish | Termination | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Number of Positions/Bay/Row | Pitch | Pitch | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 36 | 1 | Right Angle Through Hole | Non Specified - Single Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Single | Copper Alloy | Gold | Solder Wire Wrap | Female | -40 C | 105 ░C | Cantilever | 36 | 3.18 mm | 0.125 in | ||||
 EDAC Inc. | Polyester Thermoplastic | 36 | Through Hole | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Dual | Copper Alloy | Gold | Solder | Female | -40 C | 105 ░C | Cantilever | 3.18 mm | 0.125 in | 2 | 2 | 18 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 36 | Board Edge Straddle Mount | Non Specified - Dual Edge | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Dual | Copper Alloy | Gold | Solder | Female | -40 C | 105 ░C | Cantilever | 3.18 mm | 0.125 in | 2 | 2 | 18 | Card Extender | ||||
 EDAC Inc. | 36 | 1 | Through Hole | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Single | Copper Alloy | Gold | Solder | Female | -40 C | 105 ░C | Cantilever | 36 | 3.18 mm | 0.125 in | Card Guides | |||||||
 EDAC Inc. | Polyester Thermoplastic | 36 | Right Angle Through Hole | Non Specified - Dual Edge | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Dual | Copper Alloy | Gold | Solder Wire Wrap | Female | -40 C | 105 ░C | Cantilever | 3.18 mm | 0.125 in | 2 | 2 | 18 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 36 | 1 | Through Hole | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Single | Copper Alloy | Gold | Solder | Female | -40 C | 105 ░C | Cantilever | 36 | 3.18 mm | 0.125 in | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 36 | 1 | Right Angle Through Hole | Non Specified - Single Edge | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Single | Copper Alloy | Gold | Solder Wire Wrap | Female | -40 C | 105 ░C | Cantilever | 36 | 3.18 mm | 0.125 in | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 36 | 1 | Right Angle Through Hole | Non Specified - Single Edge | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Single | Copper Alloy | Gold | Solder Wire Wrap | Female | -40 C | 105 ░C | Cantilever | 36 | 3.18 mm | 0.125 in | ||||
 EDAC Inc. | Polyester Thermoplastic | 36 | Board Edge Straddle Mount | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Dual | Copper Alloy | Gold | Solder | Female | -40 C | 105 ░C | Cantilever | 3.18 mm | 0.125 in | 2 | 2 | 18 | Card Extender | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 36 | 1 | Through Hole | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | Single | Copper Alloy | Gold | Solder | Female | -40 C | 105 ░C | Cantilever | 36 | 3.18 mm | 0.125 in |
