PVC6H Series

Catalog

TRIMMER 20K OHM 0.5W PC PIN SIDE

Part	Resistive Material	Resistance	Mounting Type	Tolerance	Adjustment Type	Power (Watts)	Power (Watts)	Termination Style	Number of Turns	Temperature Coefficient	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
Bourns Inc. PVC6H203C01B00	Ceramic	20 kOhms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H101A01B00	Ceramic	100 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H204A01B00	Ceramic	200000 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H100A01B00	Ceramic	10 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H254C01B00	Ceramic	250000 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H201C01B00	Ceramic	200 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H504A01B00	Ceramic		Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H251A01B00	Ceramic	250 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H103A01B00	Ceramic	10000 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
Bourns Inc. PVC6H503C01B00	Ceramic	50000 Ohms	Through Hole	10 %	Side Adjustment	0.5 W	0.5 W	PC Pins	1	100 ppm/°C	0.315 in	0.272 in	8 mm	6.9 mm
