395-005 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 5POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Rows | Color | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Number of Positions | Card Type | Mounting Type | Contact Finish | Gender | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Number of Positions/Bay/Row | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | Wire Wrap | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | Wire Wrap | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | Wire Wrap | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Right Angle Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm | Solder | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Right Angle Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm | Solder | Side Mount Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | 0.128 " | 3.25 mm | Solder | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | Solder | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | Solder | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 1 | Black | Copper Alloy | -40 C | 105 ░C | Cantilever | 5 | Non Specified - Single Edge | Through Hole | Gold | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Single | 5 | 0.1 " | 2.54 mm | 0.156 " | 3.96 mm | Solder |
