AWL254 Series

Catalog

CONN UNSHROUDED HEADER HDR 8 POS 2.54MM SOLDER RA THRU-HOLE BAG

...

Part	Mounting Type	Contact Length - Post	Contact Length - Post	Number of Rows [custom]	Contact Finish - Mating	Contact Length - Mating	Contact Length - Mating	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Contact Shape	Fastening Type	Current Rating (Amps)	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Material	Shrouding	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Insulation Material	Contact Type	Insulation Height	Insulation Height	Number of Positions	Connector Type	Insulation Color	Termination	Overall Contact Length	Overall Contact Length	Contact Length - Mating [x]
Assmann WSW Components AWL254-DA-G08D	Right Angle Through Hole	0.118 in	3 mm	2	Gold	6 mm	0.236 in	All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.197 "	5 mm	8	Header Cuttable	Black	Solder
Assmann WSW Components AWL254-DG-Z28D	Through Hole	0.118 in	3 mm	2		6 mm	0.236 in	All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass		UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	28	Header Cuttable	Black	Solder	0.453 in	11.5 mm
Assmann WSW Components AWL254-DA-G72D	Right Angle Through Hole	0.118 in	3 mm	2	Gold	6 mm	0.236 in	All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.197 "	5 mm	72	Header Cuttable	Black	Solder
Assmann WSW Components AWL254-DA-G42D	Right Angle Through Hole	0.118 in	3 mm	2	Gold	6 mm	0.236 in	All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.197 "	5 mm	42	Header Cuttable	Black	Solder
Assmann WSW Components AWL254-DG-G46A	Through Hole	0.118 in	3 mm	2	Gold	7 mm		All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	46	Header Cuttable	Black	Solder	0.492 in	12.5 mm	0.276 in
Assmann WSW Components AWL254-DG-G56A	Through Hole	0.118 in	3 mm	2	Gold	7 mm		All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	56	Header Cuttable	Black	Solder	0.492 in	12.5 mm	0.276 in
Assmann WSW Components AWL254-DG-G38D	Through Hole	0.118 in	3 mm	2	Gold	6 mm	0.236 in	All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	38	Header Cuttable	Black	Solder	0.453 in	11.5 mm
Assmann WSW Components AWL254-DG-G66A	Through Hole	0.118 in	3 mm	2	Gold	7 mm		All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	66	Header Cuttable	Black	Solder	0.492 in	12.5 mm	0.276 in
Assmann WSW Components AWL254-DG-Z46D	Through Hole	0.118 in	3 mm	2		6 mm	0.236 in	All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	46	Header Cuttable	Black	Solder	0.354 "	9 mm
Assmann WSW Components AWL254-DG-G06A	Through Hole	0.118 in	3 mm	2	Gold	7 mm		All	-40 C	105 ░C	Square	Push-Pull	3 A	0.1 in	2.54 mm	Brass	Unshrouded	UL94 V-0	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT) Glass Filled	Male Pin	0.098 "	2.5 mm	6	Header Cuttable	Black	Solder	0.492 in	12.5 mm	0.276 in
