725-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 22POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Card Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Contact Type | Number of Positions | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Number of Rows | Termination | Color | Gender | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 22 | Non Specified - Single Edge | Through Hole | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Cantilever | 22 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | -40 C | 105 ░C | Single | 1 | Press-Fit | Black | Female | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 22 | Non Specified - Single Edge | Through Hole | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Cantilever | 22 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | -40 C | 105 ░C | Single | 1 | Press-Fit | Black | Female | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 22 | Non Specified - Single Edge | Through Hole | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Cantilever | 22 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | -40 C | 105 ░C | Single | 1 | Press-Fit Wire Wrap | Black | Female | ||
 EDAC Inc. | Polyester Thermoplastic | 11 | Non Specified - Dual Edge | Through Hole | 30 Áin | 0.76 Ám | 0.1 " | 2.54 mm | Cantilever | 22 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | -40 C | 105 ░C | Dual | Press-Fit Wire Wrap | Black | Female | 2 | 2 |
